Specification

• Battery
  48V 25Ah High-tech Lithium Battery
• Motor
  Peak 1200W High Speed Brushless Geared Motor
• Bike Frame
  26" * 18" AL6061 M Mode
• Display
  KT-LCD10H E-bike Display USB
• Charger
  US Standard 3.0A Smart Charger
• Rear Cassette
  Shimano 7 Gears
• Pedal Assist Intelligent
  5 Level Pedal Assist
• Tires
  26" x 4"
• Charging Time
  6~9 Hours
• Product Weight
  77 Ibs / 83 lbs
• Recommended Rider Heights
  5.5" ~ 6.8"
• Total Payload Capacity
  400 lbs

Components

• Throttle
  Half twist throttle
• Pedal
  Alloy pedal with reflectors
• Bike Frame
  6061 Aluminum frame
• Headlight
  48V LED light
• Handlebars
  Premium ergonomic
• Saddle
  Soft saddle
• Kickstand
  Heavy duty aluminum
• Seat post
  Diameter 30.4mm length 300mm
• Spokes
  Steel ED
• Chain
  KMC chain
• Brake
  Hydraulic Disc Brake
• Stem
  Promax MA-400 SSABK
• Crank
  170mm Forged Alloy
• Gearing
  Shimano- 14-28T BROWN/BK
• Brake lever
  Alu alloy comfort grip levers with motor cutoff switch
• Freewheel
  Shimano 7 speed gear shift system
• Front Fork
  RST Alloy front suspension fork with lockout and adjustment
• Rear Suspension
  FASTACE A8 / 850Bls / 185mm Length - Travel 50mm

Geometry

• A :
  Total Length 81.9"
• B :
  Wheelbase 52"
• C :
  Wheel Diameter 28"
• D :
  Chain Stay Length 21"
• E :
  Top Tube Length 24.6"
• F :
  Handlebar Height 43"
• G :
  Standover Height 31"
• H :
  Handlebar Length 28"
• I :
  Standover Height 29"
• J :
  Maximum Seat Height 41"
• K :
  Minimum Seat Height 34"
